Industrial Waterproof Panel PC for Food Processing
- True Flat with Aluminum Front Bezel,Fanless Design -
For the food processing industry, commercial kitchens, and central kitchens where oil, steam, and frequent cleaning are part of daily operations, a reliable Industrial Waterproof Panel PC is an essential display device.
Designed with IP65-rated waterproof protection, this panel PC can withstand water splashes and detergent wiping during routine sanitation. Its fanless structure prevents dust and grease from entering the system, ensuring long-term stability and extending the lifespan of the panel computer in harsh working environments.
Key Features of the Waterproof Panel PC
-
IP65-Rated Waterproof Protection – Resists water spray and cleaning agents, making it ideal for environments that require daily sanitation.
-
Stainless Steel or Aluminum Enclosure – Offers durability and corrosion resistance suitable for food-grade environments.
-
Fanless Thermal Design – Minimizes dust accumulation and prevents air contamination during food production.
-
Wide Temperature & Humidity Tolerance – Ensures reliable operation in kitchens and production areas with fluctuating temperatures.
-
Easy-to-Clean Flat Front Panel – Seamless design without gaps or vents prevents residue buildup.
-
Flexible OS Support (Windows / Linux) – Compatible with both Windows and Linux operating systems, allowing integration with various factory automation, POS, and monitoring software.
Why Choose Our Industrial Waterproof Panel PC ?
With over 30 years of experience in industrial PC design and manufacturing, we build reliable and customizable systems tailored for food-processing and industrial environments.
Our design focuses on 12 to 23.8-inch panel sizes ( Max. 32" ) , providing the ideal balance between readability, installation flexibility, and production efficiency.
Each unit features an optically bonded touch display, which eliminates internal air gaps, reduces reflections, and enhances clarity even under strong ambient lighting.
This bonding process also improves vibration resistance and prevents moisture condensation, ensuring stable visibility and long-term reliability in demanding conditions.
To suit various environments, we offer optional specifications including:
-
Wide-temperature operation (–20°C to +60°C) for consistent performance under extreme heat or cold.
-
Anti-Glare surface treatment to diffuse harsh reflections, ensuring clear visibility in bright kitchens or stainless-steel surroundings.
-
Anti-UV coating to protect the display from yellowing and material degradation caused by prolonged exposure to strong light.
For hygiene-sensitive applications, stainless-steel enclosures in SUS304 or SUS316 are available, allowing clients to balance corrosion resistance, sanitary standards, and cost considerations.
The default aluminum housing provides excellent heat dissipation and lightweight durability, making it suitable for most food and industrial installations.
As a flexible, experienced mid-sized manufacturer, we provide responsive customization—from system configuration to mechanical design—and welcome open collaboration to meet your exact requirements.
Applications in Food & Beverage Industry
This industrial waterproof panel PC is engineered for hygiene-critical and moisture-heavy environments, such as:
-
Food and beverage production lines
-
Restaurant and hotel kitchens
-
Central kitchen automation systems
-
Dairy and meat processing facilities
-
Beverage bottling and packaging areas
With dual OS compatibility (Windows and Linux), it can seamlessly run software for production control, recipe management, or real-time monitoring.
This flexibility ensures that whether your operation relies on Windows-based ERP systems or Linux-driven automation tools, the waterproof panel PC integrates smoothly into existing workflows—helping operators manage data efficiently, even under high humidity and frequent cleaning conditions.
Rugged Aluminum Housing with IP65 Protection
Our IP65 Aluminum Panel PC series is built with lightweight yet durable aluminum enclosures, offering full protection against dust, moisture, and water spray. The corrosion-resistant design makes it an ideal solution for environments where stainless steel is not required, but industrial-grade reliability is still essential.
 Prevents Condensation |  IP65 Full Water-Proof |  Water-Proof M12 I/O port |
|---|
Fanless Design with Wide Temperature & Voltage Support
Engineered as a fanless industrial panel PC, the system ensures silent and reliable operation in harsh conditions. With wide temperature tolerance (-20°C to +70°C) and flexible DC 9–36V power input, the IP65 aluminum panel PC adapts seamlessly to factory automation, kiosk, and industrial control applications.
Flexible Display & Touch Options for Versatile Use
Available in multiple screen sizes, the IP65 Aluminum Waterproof Panel PC supports both projected capacitive (PCAP) multi-touch and resistive touch options. Anti-glare, anti-reflective, and anti-fingerprint coatings are available, along with optical or air bonding for improved visibility. Its true-flat design ensures easy cleaning and integration across food processing, retail, and automation industries.
Specification of the Waterproof Panel PC
General Mechanical Drawing
I/O Port- & Operation Buttons
🔌 I/O Ports
-
Video Output: VGA, DVI, HDMI
-
USB Ports: Multiple USB 2.0 / USB 3.0 ports
-
LAN Ports: 2 × RJ45 Gigabit LAN
-
Serial Ports: 2 × COM (RS-232/422/485 selectable)
-
Audio: Line-out, Mic-in
-
Power Input: DC-in connector
⚙️ Operation Buttons (OSD & Control)
-
Power Button: System on/off
-
Menu / Select: OSD menu navigation and selection
-
Brightness Control: Increase / decrease brightness
-
Navigation Keys: Up / Down function keys
Wall-Mount Type & Stand
Industrial Rugged Tablet PC Specifications
Display Type
-
12" ~ 23.8" TFT LCD (Intel Atom & Elkhart Series)
-
12" ~ 23.8" TFT LCD (Intel Core Kaby/Whiskey/Tiger Series)
Max. Colors
-
16.7M
Luminance
-
250 cd/m² ~ 1500 cd/m²
Viewing Angle
-
160° ~ 178° (Horizontal), 160° ~ 178° (Vertical)
LED Backlight (Hours)
-
30,000 ~ 70,000 hrs
Touchscreen
-
Resistive or Projected Capacitive (1-point resistive, 10-point PCAP)
Processor
-
Intel Atom Celeron Processor Bay Trail J1900, 10W
-
Elkhart Lake J6412/6413, 10W
-
Intel Kaby/Whiskey/Tiger Lake Processor
- Kaby (7th): Celeron 3965U, Core i3-8145UE, i5-8365UE, i7-8665UE, 15W
- Tiger (11th): Celeron 6305E, Core i3-1115G4E, i5-1145G7E, i7-1185G7E, 28W
System Memory
-
DDR3L or DDR4 SO-DIMM up to 16GB/32GB (Atom & Elkhart Series)
-
DDR4 SO-DIMM up to 32GB/64GB (Core Kaby/Whiskey/Tiger Series)
Chipset
-
Integrated
Network
2 × Gigabit LAN Ethernet
I/O Ports
-
Intel Atom & Elkhart Series:
- 2 × USB 2.0, 2 × USB 3.0, 2 × RS-232, 1 × RS-232/422/485, VGA, HDMI, DC-in Jack
-
Intel Core Kaby/Whiskey/Tiger Series:
- 4 × USB 3.0, 2 × USB 2.0, 2 × RS-232, 1 × RS-232/422/485, VGA, HDMI, DC-in, DP
OS Support
-
Windows 10 IoT, Linux (Atom & Elkhart Series)
-
Windows 10/11, Linux (Core Kaby/Whiskey/Tiger Series)
Power Input
-
DC 12–24V wide voltage (Optional 9~36V)
Mounting
-
VESA / Clamp mounting
Operating / Storage Temperature
-
0°C ~ +50°C (32°F ~ 122°F)
-
-20°C ~ +60°C (-4°F ~ 140°F) (wide temp option)
Certification
-
CE, FCC, RoHS
Optional Modules
-
Wi-Fi, Bluetooth, Barcode scanner, RFID, MSR
Reliable Waterproof Panel Computer Designed in Taiwan, Shipped to Japan
Our factory in Taiwan specializes in designing and manufacturing rugged panel computer that meet the demanding standards of Japanese importers and end-users.
-
Built for Harsh Environments: Fanless design, IP65 protection, and durable touchscreens for warehouse, factory and outdoor use.
-
Long Life cycle Support: We ensure stable supply and extended product availability, ideal for Japanese distributors who value long-term reliability.
-
Flexible Customization: OEM/ODM options available, including logo branding, size, I/O customization, add-on device and software pre-installation.
-
Fast Delivery to Japan: Located in Taiwan, we can ship quickly to Japan with stable logistics support.
FAQ
Q1. Can this waterproof panel PC be washed directly with water?
Yes. The front panel is IP65-rated and can withstand low-pressure water jets and detergent wipes. However, direct high-pressure cleaning should be avoided.
Q2. What materials are available for the housing?
You can choose between SUS304 or SUS316 stainless steel, depending on the corrosion resistance and hygiene standards required.
Q3. Is it suitable for 24/7 operation?
Absolutely. The fanless cooling and industrial-grade components ensure continuous and stable operation in 24/7 production environments.
Q4. Can I customize the screen size or connectors?
Yes. Screen sizes, I/O ports, and mounting types can be customized according to your application needs.
Q5. How fast can Taiwan-made rugged panel computer be shipped to Japan?
With our proximity in Taiwan, we can provide shorter lead times compared to US or European suppliers. Standard shipments to Japan are fast and reliable via UPS, DHL, or sea freight.
Inquiry Now for Industrial Waterproof Panel PC
Upgrade your food processing line with a reliable waterproof panel PC designed for safety, hygiene, and performance.
📩 Contact us today to discuss your specifications or request a quotation.
