Fixed Mount Barcode Scanner

Resolution: 3 mil 1D, 6.67mil 2D
Auto-sense function saves power for improve life time
Read all 1D standard and 2D barcodes
Multi-interface solution
With LEDs and speaker for scanning confirmation

CM-980 Fixed Mount Barcode Scanner for Kiosks and High-Speed Retail Checkout

The CM-980 is an omnidirectional presentation imager designed for superior performance and versatility. It can also be configured as a Fixed Mount barcode scanner, making it an excellent choice for integration into Kiosk systems or for high-speed barcode scanning at checkout counters in retail stores. With its high-performance 2D CMOS imager, elegant housing, and durable build, the CM-980 is ideal for POS check-out environments, marketing promotion barcode scanning, and applications in the medical and banking industries.

This Fixed Mount barcode scanner is engineered to deliver fast, reliable decoding of most standard 1D, PDF, and 2D barcodes. It reads e-barcodes, damaged codes, and poorly printed labels with ease, making it perfect for Kiosk installations that require consistent scanning performance. Retailers can efficiently serve customers who present mobile coupons or loyalty cards directly from smartphones, while restaurants can redeem mobile offers instantly at the register.

Hotels can allow guests to use electronic loyalty cards stored on their mobile devices, eliminating the need for physical cards. Theaters, theme parks, and stadiums can scan both e-tickets and paper tickets with equal ease, offering customers the convenience of paperless ticketing. Whether deployed in Kiosk systems, integrated into self-service terminals, or positioned for high-speed barcode scanning at checkout counters, the CM-980 ensures fast, accurate, and seamless customer transactions.

Quality you can see, performance you can trust

At CANMAX, Our rigorous testing process ensures that each bluetooth barcode scanner meets the highest standards.

We use the latest available test tools and machines to check materials, semi-finished parts and finished bluetooth barcode scanners to deliver the reliability and peace of mind that our customers deserve.

Discover the features of our Fixed mount Barcode Scanner

Applications

Retail POS and Checkout – Ideal for high-speed barcode scanning at checkout counters in supermarkets, convenience stores, and specialty shops.
Self-Service Kiosks – Can be integrated as a Fixed Mount barcode scanner in Kiosk systems for ticketing, self-check-in, and bill payment.
Hospitality – Hotels can scan mobile loyalty cards or digital check-in codes directly from guests’ smartphones.
Restaurants and Quick Service – Redeem mobile coupons, scan order tickets, and accelerate payment processing at the register.
Entertainment Venues – Theaters, theme parks, and stadiums can validate e-tickets and paper tickets quickly and accurately.
Healthcare – Scan patient ID wristbands, prescription labels, and lab sample barcodes for fast data entry.
Banking and Financial Services – Read barcodes on forms, IDs, and electronic vouchers for customer transactions.
Marketing Promotions – Easily scan e-barcodes from mobile devices for discount coupons and loyalty programs.

Flexible and easy to integrate

the back view of fixed mount barcode scanner

Our fixed mount barcode scanner features a mechanism design that allows for easy insertion of the interface cable into the table. The reader also comes with screw holes on the bottom of the case, making it simple to securely fasten the device to self-service kiosks or tables. Best of all, integrating the Passport Reader into your product designs is effortless, as it doesn't require any mechanical or electrical engineering.

Specification

General

Interface

USB-KB / USB-COM / RS-232
Readable Codes 1D

UPC-A, UPC-E, EAN-13, EAN-8, Code 128, GS1-128, Code-39, Code-32, Code-93, Pharmacode Codabar/NW7, MSI, Interleaved 2 of 5, GS1 DataBar-14, GS1 DataBar Stacked, GS1 DataBar Limited GS1 DataBar Expanded, GS1 DataBar Expanded Stacked, Composite Component A / B / C
Readable Codes 2D

PDF 417, MicroPDF 417, QR Code, Micro QR Code, Dara Matrix, Aztec, Maxi Code, Dot Code

Optical

Optical System

1280 H x 800 V pixels
Light Source

Illumination: Red 630nm LEDs
Resolution

3mil Code-39, 6.67mil DataMatrix
Frame Rate

60 FPS
Field of View

Horizontal: 61°; Vertical: 41°
Indicator

Speaker, LED

Electrical

Voltage

DC 5V
Scanning Currents

230 mA
Standby Currents

160 mA

Environment

Operating Temperature

0 °C to 40 °C (32ºF to 104ºF)
Storate Temperature

-40°C to 70 °C (-40ºF to 158ºF)
Relative Humidity

5% - 95% RH (non-condensing)
Shock resistance

1.5m drops

Physical

Weight

510g w/cable
Dimensions

148.8mm (W) x 97.41mm (H) x 142.59m (D)
Housing Material

PC + ABS plastic
Cable

Length: 5ft (150cm), USB Type: A, RS-232
Warranty

1 year
Certificate

CE / FCC

FAQs

1. How to configure the Fixed Mount Barcode Scanner?
- Our Fixed Mount barcode scanners come with a user manual for users, software for our distributors or to combine multiple readers. We also provides commands to enable a programmer to control the readers from a user's terminal.

2. Are the Fixed mount barcode scanner compatible with the Zebra DS457 fixed mount scanner's connection with Windows OS?

-Yes, our fixed mount barcode scanner is compatible with the Windows built-in driver, making it a suitable replacement for the Zebra ds457 fixed mount scanners.

Inquiry Now for CM-980

Upgrade to the Fixed Mount barcode scanner today and enjoy the convenience and cost-saving benefits of a scanner that offers three different modes of operation in one device.
